| Configuration |
Powered low cabinet or subwoofer |
| LF transducer |
1×15” Neodymium |
| Freq. response high-power efficiency |
60 Hz to 120 Hz |
| Freq. response sub low |
38 Hz to 120 Hz |
| Max SPL |
138 dB |
| Amplifier |
Class D | 1.800W RMS – 3.600W peak |
| AC Power input |
100 VAC – 4,8A | 120 VAC – 4A | 240 VAC – 2A |
| Controls |
Power – Rotary encoder – Selection button – 2x level |
| Indicators |
LCD display – Rotatable multipurpose front LED indicator (power, limiter, network, off) – 3x signal LED – Network LEDs |
| Connectors |
2x XLR/F 1/4” combo – 2x XLR/M loopthrough – 1x XLR/M mixout – 2x RJ45 4×4 Dante(AES67) & Control |
| Extra connectivity |
Multicast Bluetooth® receiver/sender – NFC |
| Enclosure |
Wood |
| Colour |
Black (RAL 9011) |
| Grill |
Powder coated steel – Internal lining |
| Dimensions (WxHxD) |
620 x 625 x 475 mm – 24.41 x 24.61 x 18.70 in |
| Net weight |
41 kg – 30.39 lb |
| Attachment |
Internal rigging – 2x M20 |
| Optional accessories |
Yoke – Rigging bumper – Vertical coupler SOLIDPROTECT – WHEELPLATE15 – Touring dolly COVER15 |
