I. Thông số kỹ thuật
| Input | Microphone / Line Input: 1-24 (local) | Balanced, XLP and 1/4 TRS jacks | control | Fader | 26 ALPS 100mm electric |
| Input sensitivity (XLR/TRS) | XTR1.5mv, TRS 7mv | touch screen | 10.1” TFT, 1280×800 resolution | ||
| Input analog gain | -32db to 10db, 0.6~0.7 stepping | DCA marshalling | eight | ||
| Maximum input level (XLR/TRS) | +19dBu/+29dBu | Mute grouping | eight | ||
| Input impedance (XLR/TRS) | MIC＞5K ，LINE＞10K | Mute marshalling | TCP/IP Ethernet for PC and iPad applications | ||
| Mic input stereo link | Have | System Upgrade | U disk upgrade | ||
| Parameter link | Equalization, dynamic, delay, distribution, transmission | Wired connection | Windows PC software connection | ||
| polarity | Normal/flip | Wireless connections | Wireless connections | ||
| Stereo line input | Input processing | Input source | Local CH1-CH24, ST1/ST2 local ST3 digits | ||
| ST1/ST2 | 3.5 lotus socket | Equalizer | 5-parameter EQ, (20HZ–20KHZ) ±12dB, Q0.3~15 adjustable | ||
| ST3 interface (digital) | USB audio stream, U disk, S/PDIF | High and low pass | 12db/24db,(BT/BS/LRK),20-20K | ||
| Input sensitivity | Nominal 4dB | Noise gate | Chain side chain | ||
| Input analog gain | -32db to 10db, 0.6~0.7 stepping | Gate threshold | -135db to -40db | ||
| Maximum input level | +29dB | Shock/release | 50us-300ms/10ms-5s | ||
| input resistance | >7KΩ | Compressor | Chain side chain | ||
| Stereo link | Have | Threshold ratio | -40db-+6db/1:1 to infinity | ||
| Parameter link | Equalization, dynamic, delay, distribution, transmission | Delay | 20ms maximum | ||
| polarity | Normal/flip | Remote extension | Support two connection interface box | ||
| Output | Mix 1-14 with left and right output (local) | Balance, XLR, L/R, 8AUX | Output processing | Output channel | L/R,14AUX |
| Output impedance | <75Ω | Equalizer | 15-31parameter EQ, (20HZ–20KHZ) ±12dB, Q0.3~15 adjustable | ||
| Nominal output | +4dbu=0db meter reading | High and low pass | 12db/24db,(BT/BS/LRK),20-20KHZ | ||
| Residual output noise | =-91dbu | Compressor | Chain side chain | ||
| Mixing insertion | Assign FX to the mixing channel | Threshold ratio | -40db-+6db/1:1 to infinity | ||
| Dynamic Range | 112dB | Delay | 30ms maximum | ||
| Signal to noise ratio | XLR≥ 92db,TRS≥82db | USB | drive | CH340(USB A) | |
| Maximum output voltage | 4VAC MAX | device | Use a USB hard drive (U disk) | ||
| Distortion | ＜0.0003%（1KhzFull Power） | Stereo recording | 2 channels (wav/mp3) 48KHz 24 | ||
| 2 channels (wav/mp3) 48KHz 24 | 20HZ-20KHZ+/-0.5db | Stereo playback | 2-way (WAV/MP3) 32-96KHz, 16-24 bits | ||
| Sampling Rate | 48KHz ±100PPM | USB audio | Sound card | USB B | |
| ADC/DCA | 24-bit Delta-sigma | Send uplink | 8-channel full format, 32KHz-96KHz 24 bit | ||
| FX | internalFX | 4xFX engine, send > return
or insert |
Send down | 8 channels, MP3, 48KHz, 24 bits | |
| Types of | Reverb, delay, chorus, flanger, symphony, etc. | Dante | support | ||
| 2 dedicated stereo FX returns | Fader, pan, mute, send
to mix/LR, 5 segment EQ |
automatic
mixing |
support | ||
| system | Linux system | Chinese and English language switching | power supply | 100-240VAC,50-60H,150W | |
Length, width and height: 746*509*248MM (the length includes 6.35 input socket, the width includes the side panel, the height includes the machine foot; the knob is not included)
Packing size: 915*625*360MM
Net weight: 15.6KG Gross weight: 20.5KG
